Omega Linear Gen3

Omega Linear Gen3 is a versatile, top quality and cost-effective professional luminaire.

With a long warranty, easy maintenance and outstanding light output/energy efficiency, the Omega Linear Gen3 is the smart choice. The clear-lined luminaire which provide spectacular illumination for both low and high spaces.

For the lighting designer and end user, the Omega Linear Gen3 provides high quality lighting with low glare, supporting visual efficiency, work safety and flawlessness. The luminaire meets the requirements of the EN-12464-1 indoor lighting standard.

The names of the light distribution files allow you to select the right luminaire for the right application.

Industrial IP20: General lighting Wide UGR 21-25, workstation lighting Medium UGR 13-16

Retail: Wide UGR 21-25 , warehouses Wide UGR 21-24

Logistics : Shelf spacing High Rack UGR 21-25, high open storages Medium UGR 17-19

Offices, corridors and lobbies: Wide UGR 18-21

New

Application area: shops, warehouses, offices, corridors, hallways and IP20 industry
Installation: ceiling surface, ramp, suspension and hanging rail

Benefits

The steel body is galvanised as standard, with white (RAL 9010) available as an option. The luminaire is equipped with a DALI control gear as standard and is also available as a wireless Bluetooth NLC or CASAMBI solution.

Luminaire-specific sensor: the luminaire with motion and presence sensor has an NLC Bluetooth or Casambi sensor integrated into the side of the luminaire to improve wireless network coverage.

Maintainability: the luminaire is maintainable with Zhaga standard Zhaga Book 7 -W4 linear LED card or 2R led linear card and optics, by Greenled and other lighting professionals. In addition, the luminaire can be fitted with Zhaga Book 13 linear control gear. The Zhaga Book 20 and Zhaga Book 25 standards ensure serviceability and availability of spare parts.

Applicability

Ideal for lighting shops, general offices, production areas and indoor warehouses. Wide range of different optics. The luminaire is available in 3 different lengths.

Installation

Ramp bracket, ceiling surface, pendant and luminaire suspension rail and can be supplied complete with EnstoNet or Wago Winsta cables. The luminaire does not need to be opened for installation and the cables can be discreetly hidden in a recess in the top of the frame.

Omega Linear Gen3 is suitable for both wireless and wired control applications

Variants

Type code	Power	Luminous flux	Luminaire efficacy	Lifetime	Operating temperature
GLOLG312015	15 W	2501 lm	169 lm/W	L80B50 > 100 000h, C10 100 000h	0 - +40°C
GLOLG312021	21 W	3556 lm	167 lm/W	L80B50 > 100 000h, C10 100 000h	0 - +40°C
GLOLG312027	27 W	4595 lm	168 lm/W	L80B50 > 100 000h, C10 100 000h	0 - +40°C
GLOLG312035	35 W	5960 lm	169 lm/W	L80B50 > 100 000h, C10 100 000h	0 - +40°C
GLOLG312055	55 W	8608 lm	156 lm/W	L80B50 > 100 000h, C10 100 000h	0 - +40°C
GLOLG312074	74 W	11458 lm	156 lm/W	L80B50 > 100 000h, C10 100 000h	0 - +40°C
GLOLG312089	89 W	13288 lm	150 lm/W	L80B50 > 100 000h, C10 100 000h	0 - +40°C
GLOLG318022	22 W	3753 lm	171 lm/W	L80B50 > 100 000h, C10 100 000h	0 - +40°C
GLOLG318031	31 W	5334 lm	173 lm/W	L80B50 > 100 000h, C10 100 000h	0 - +40°C
GLOLG318039	39 W	6894 lm	176 lm/W	L80B50 > 100 000h, C10 100 000h	0 - +40°C
GLOLG318056	56 W	9444 lm	170 lm/W	L80B50 > 100 000h, C10 100 000h	0 - +40°C
GLOLG318071	71 W	11736 lm	166 lm/W	L80B50 > 100 000h, C10 100 000h	0 - +40°C
GLOLG318099	99 W	15784 lm	160 lm/W	L80B50 > 100 000h, C10 100 000h	0 - +40°C
GLOLG318131	131 W	19917 lm	152 lm/W	L80B50 > 100 000h, C10 100 000h	0 - +40°C
GLOLG324028	28 W	5003 lm	177 lm/W	L80B50 > 100 000h, C10 100 000h	0 - +40°C
GLOLG324041	41 W	7112 lm	174 lm/W	L80B50 > 100 000h, C10 100 000h	0 - +40°C
GLOLG324070	70 W	11919 lm	170 lm/W	L80B50 > 100 000h, C10 100 000h	0 - +40°C
GLOLG324101	101 W	16564 lm	165 lm/W	L80B50 > 100 000h, C10 100 000h	0 - +40°C
GLOLG324140	140 W	22295 lm	160 lm/W	L80B50 > 100 000h, C10 100 000h	0 - +40°C
GLOLG324157	157 W	24752 lm	158 lm/W	L80B50 > 100 000h, C10 100 000h	0 - +40°C
GLOLG324175	175 W	26556 lm	152 lm/W	L80B50 > 100 000h, C10 100 000h	0 - +40°C
GLOLG324180	180 W	30507 lm	170 lm/W	L80B50 > 100 000h, C10 100 000h	0 - +40°C
GLOLG324223	223 W	37010 lm	166 lm/W	L80B50 > 100 000h, C10 100 000h	0 - +40°C

Dimensions

Type code	Length (L)	Height (H)	Width (W)	Weight
GLOLG312015	1156mm	51mm	65mm	2,3 kg
GLOLG312021	1156mm	51mm	65mm	2,3 kg
GLOLG312027	1156mm	51mm	65mm	2,3 kg
GLOLG312035	1156mm	51mm	65mm	2,3 kg
GLOLG312055	1156mm	51mm	65mm	2,3 kg
GLOLG312074	1156mm	51mm	65mm	2,3 kg
GLOLG312089	1156mm	51mm	65mm	2,3 kg
GLOLG318022	1720mm	51mm	65mm	3,2kg
GLOLG318031	1720mm	51mm	65mm	3,2kg
GLOLG318039	1720mm	51mm	65mm	3,2kg
GLOLG318056	1720mm	51mm	65mm	3,2kg
GLOLG318071	1720mm	51mm	65mm	3,2kg
GLOLG318099	1720mm	51mm	65mm	3,2kg
GLOLG318131	1720mm	51mm	65mm	3,2kg
GLOLG324028	2283mm	51mm	65mm	4,0 kg
GLOLG324041	2283mm	51mm	65mm	4,0 kg
GLOLG324070	2283mm	51mm	65mm	4,0 kg
GLOLG324101	2283mm	51mm	65mm	4,0 kg
GLOLG324140	2283mm	51mm	65mm	4,0 kg
GLOLG324157	2283mm	51mm	65mm	4,0 kg
GLOLG324175	2283mm	51mm	65mm	4,0 kg
GLOLG324180	2283mm	51mm	65mm	4,0 kg
GLOLG324223	2283mm	51mm	65mm	4,0 kg

Colour temperature:
3000, 4000 ⁽¹

Colour rendering index:
RA≥ 80

Optics:
PMMA

Enclosure class:
IP20

Supply voltage:
220-240 Vac

Frequency:
50-60 Hz

PF:
>0.90

THD:
<20%

Connection:
Chained and bushing max 5*2,5mm2 OR max 3*2,5mm2 and DALI +/-

Controllability:
DALI2 data, On/Off, NLC ecg⁽², NLC node, NLC+ PIR sensor, Casambi+ PIR sensor

Colour:
Galvanised steel (optional white RAL 9010).

Body material:
Steel

Warranty:
5 years or 8 years. 2 years or 5 years for luminaire-specific sensors.

Accessories (installation):
E1500240 Omega Linear ceiling bracket, E1500239 Omega linear Mek bracket 50-110mm , 9905206 Omega Linear ladder rack and threaded rod bracket, 9905205 Omega Linear adjustable ceiling bracket, 9905203 Omega Linear adjustable suspension rail 70 bracket, 9905204 Omega Linear adjustable suspension rail 120 bracket, E1500236 Omega Linear Gen3 railbracket medium galvanised, E1500238 Omega Linear Gen3 railbracket medium white, E1500237 Omega Linear Gen3 railbracket long galvanised, E1500235 Omega Linear Gen3 railbracket long white, E1500244 Omega Linear Gen3 railbracket 0-45 degrees medium, galvanised, E1500243 Omega Linear Gen3 railbracket 0-45 degrees medium, white, E1500242 Omega Linear Gen3 railbracket 0-45 degrees long, galvanised, E1500241 Omega Linear Gen3 railbracket 0-45 degrees long, white, Ensto and Wago quick connect cables. KTS. brackets and accessories

Comments:
1) SDCM ≤3

2)Not available for 1200 89W, 1800 131W, 2400 140W,157W,175W,180W,223W versions
