Alula

Alula is a scalable and incredibly versatile urban luminaire. Alula 5-in-1 is a single luminaire with five different mounting options, making it a designer's and architect's dream. Superior scalability from park to street with versatile light distribution. Unique implementation options with Amber lenses and Dual-channel allow you to create a modern urban environment without compromise.

New at

Application area: urban, park and area lighting

Installation: vertical and horizontal columns and wire suspension

S-type

Alula S-type is an urban outdoor luminaire designed specifically for street lighting in city centres.
Y-type

Alula Y-type is a Y-branch luminaire for urban parks.
J-type

Alula J-type is a modern and striking luminaire with a curved and sculptural design that makes it an architectural eye-catcher.
W-type / T-type

Alula W-type is an urban street luminaire for wire and pendant mounting.

Alula T-type is equipped with a thread bracket above the luminaire.

Benefits

A body made from recycled aluminium for a minimal carbon and environmental footprint. Manufactured domestically and always factory wired, the luminaire is quick and easy to install and maintain without the need for special tools. The luminaire meets common and demanding Nordic quality standards. The luminaire is equipped with standardized and serviceable Zhaga Book 15 LED caps and optics and Zhaga Book 13 standardized easy to change ballast. The LEDs used are silver-free ceramic LEDs with the longest lifetime.

The luminaire is available with one top and/or one bottom Zhaga connector.

Applicability

Alula S-type can be mounted on a vertical or horizontal pole.

Alula Y-type can be mounted on a vertical pole.

Alula J-type can be mounted on a vertical pole.

Alula W-type can be mounted either by wire rope or suspension.

Alula T-type can be installed on a G 3/4" threaded pole coming from above.

Variants

Model	Type code	Power	Luminous flux	Luminaire efficacy	Lifetime	Operating temperature	Optical safety distance ¹⁾
Alula	GLALU24070	15-70 W	max. 9731 lm	157 lm/W	L98B50 > 100 000h, C10 100 000h	-40 - +45°C	2,9 m
Alula	GLALU48137	28-137 W	max. 19463 lm	166 lm/W	L98B50 > 100 000h, C10 100 000h	-40 - +25°C	4,8 m
Alula	GLALU64144	123-144 W	max. 21201 lm	148 lm/W	L98B50 > 100 000h, C10 100 000h	-40 - +25°C	5,0 m
Alula (Amber 2C)	GLALU48272	15-72W	max. 9731 lm	136 lm/W	L98B50 > 100 000h, C10 100 000h	-40 - +25°C	2,9 m

Dimensions

Model	Type code	Height (H)	Diameter (D)	Weight	Wind surface area
Alula	GLALU24070	76 mm	Ø 500 mm	8,8 kg	2000 cm²
Alula	GLALU48137	76 mm	Ø 500 mm	9,0 kg	2000 cm²
Alula	GLALU64144	76 mm	Ø 500 mm	9,5 kg	2000 cm²
Alula (Amber 2C)	GLALU48272	76 mm	Ø 500 mm	9,0 kg	2000 cm²

Comments on

Rated luminous flux is indicative of LED luminous flux and is based on LED manufacturer's specifications at 4000K colour temperature and CRI70 colour rendering. The actual luminous flux of a luminaire depends on environmental conditions (e.g. temperature and contaminants), LED colour temperature, colour rendering and optical efficiency of the luminaire. All values at +25°C ambient temperature. For luminous flux +-10% tolerance and for power +-10% tolerance. The luminaire is CLO compensated.

1) The luminaire must be positioned so that prolonged viewing of the luminaire cannot be expected to occur at a distance closer than the optical safety distance.

Overview

Color Temperature: AMBER, 3000K, 4000K
Color Rendering Index: CRI ≥ 70
Color consistency: SDCM ≤5
Optics: PMMA
Light Source Protection: Tempered glass
Enclosure protection rating: IP66
Impact resistance: IK08
Supply Voltage: 220-240 Vac
Frequency: 50-60 Hz
Power Factor: PF > 0,90
THD: THD < 20%
Surge Protection: 10kV L/N-Ground & 6kV L-N
Connection: 3- or 5-pole factory-installed rubber cable.
Dimming / Control: ON/OFF, DALI, AstroDIM, Casambi.
Color: RAL7015 as standard, other RAL colours as an optional
Housing Material: Recycled aluminium
Warranty: 5 years (optional 8 years) - not including steering components
Accessories (Installation): C9400084 S-type pipe bracket
C9400085 Y-type park bracket
C9400086 J-type bracket
E1500261 W-type wire bracket
E1500250 T-type thread bracket
5205037 pipe adapter
3608220 pipe bracket
3608101 roof bracket
3608061 wall bracket
5206062 T-mounting piece
accessories (other): Protection Class II assembly, separate surge protection and Dual Channel White-Amber assembly (2C model)
